In front of the wall
BERLIN – provides an elegant and space efficient sliding solution
BERLIN – the premium modern barn door hardware provides an elegant and space efficient sliding solution to replace traditional doors. With a quiet and smooth mechanism, it comes in stainless steel or black finishes. The complete package includes all components for simple installation, making it a practical and stylish solution for any project.
We believe that design is more than just looks. With our door systems, we strike a perfect balance between function and aesthetics to make doors something special.
Features
Contemporary style
Stylish Innovation: BERLIN offers a seamless blend of design and functionality
Precision Components: Includes a carefully crafted track, smooth-gliding wheels, and top-quality door stops.
Complete Hardware Set: Comes with floor guides and all accessories to mount heavy duty wood and frameless glass doors.
Maximum flexibility for custom designs
- Easy To Retrofit: Convert an existing opening for a hinged door to a sliding door.
- Comfortable and Quiet: Use Soft-Stops on both sides, even on narrow doors.
- Flexible Mounting: Mounts to studs, brick and concrete walls – as long as the wall can support the weight.
A peek inside
- Robust Wheels: Designed to support larger, heavier doors effortlessly.
- Adaptable Mounting: Suitable for both glass and wooden doors.
- Straightforward Installation: Wheels attach from below for easy setup.
- Optional Distance Profile: Provides additional projection while maintaining a cohesive look.
Heavy duty carriages
- Effortless Sliding: Ball bearing wheels ensure smooth and easy movement.
- Dual Compatibility: Designed for frameless glass and wooden doors.
- Secure Operation: Anti-jump feature keeps wheels firmly on track.
- Precise Adjustment: Each wheel can be fine-tuned for perfect alignment.
To create a solution that not only fulfills all the known properties of a door, but also optimizes them through clever innovations.
Add ons
Explore the range of add-ons available for the BERLIN Barn Door Hardware, enhancing functionality and aesthetics to suit your specific needs.
Soft-Stops
- Dual Soft-Stops: Quiet and controlled sliding with gentle stops on both ends.
- Durable Design: Precision-engineered in Germany to support doors up to 176 lbs.
- Smooth Operation: Requires minimal effort for silent and seamless movement.
- Refined Craftsmanship: Ideal for those who appreciate quality and elegance.
- Wide Applicability: Compatible with doors as narrow as 25 5⁄8”
Distance profile
- Seamless Adjustment: The optional distance profile accommodates baseboards and door frames effortlessly.
- Optimal Spacing: Provides 3⁄4″ (20 mm) clearance between the wall and door for a perfect fit.
- Coordinated Design: Matches sliding door hardware for a unified appearance.
- Easy Installation: Designed to bypass existing obstructions with ease.
- Polished Finish: Includes matching end caps for a clean, complete look.
We make no compromises – our door systems combine the highest quality and individual design so that they can be perfectly adapted to your requirements and your rooms.
Technical specifications
Door panel options
Whether you prefer a minimalist, modern, or timeless style, BERLIN is compatible with both wooden door panels and frameless glass sliding doors.
Maximum door weight:
265 lb
Track dimensions:
79 3⁄4″ x 2 3⁄8“ x 2 9⁄16“ (W x H x D, 2000 mm x 60 mm x 65 mm)
Possible door width:
from 21 5⁄8” (550 mm)
Possible door thickness:
Wood doors 1 3⁄8“ – 2″ (35 mm – 52 mm)
Frameless glass doors 3⁄8“ (10 mm), 1⁄2“ (12.7 mm) and 9⁄16“ (13.5 mm)
Carriages:
Smooth and quiet ball-bearing wheels with universal threads for different Falkenstein door mounts. Tested for 100,000+ cycles at full weight capacity.
Track mounting:
The standard BOXtrack is predrilled for wall mounting, with a ceiling-mount option available on request.
Door stop:
Hold-in-place stoppers and optional Soft-Stops can easily be positioned anywhere along the track.
Optional distance profile:
For seamless integration with existing door casings or baseboards ¾“ (20 mm)
Downloads
In this section, you’ll find downloadable resources related to the product, including literature, manuals and installation instructions.
Installation Instruction
Technical details
Scope of Delivery
The BERLIN comes with all necessary components for both glass and wood doors, including a track, valance, end caps, door stops, carriages and floor guides.
Sectional View
The sleek valance discreetly conceals the heavy-duty carriages, which also function as glass clamps. The cross-sectional view highlights how the optional distance profile seamlessly adds projection to accommodate trim, casings, or baseboards.
Floor Guides for BERLIN
BERLIN floor guides are designed to keep doors sliding smoothly and quietly, adding extra stability to the system.
